The battery is shipped with a charge. Take precautions to prevent short circuits; all installation tools should be wrapped with insulating tape.

Before installing the connecting bars, wipe off dust from the battery plates, casing, and steel frame, ensuring the plates are clean.

After installation, check all screws one by one to ensure they are tightened. A designated person should inspect and confirm that all screws are in a tight condition.

The L-series batteries are lithium-ion products designed to replace lead-acid batteries. Since there is no communication function between batteries, (without battery communication, current equalization cannot be guaranteed after parallel connection).

The L-series batteries are compatible with mainstream off-grid and hybrid inverters on the market. For practical applications, 2 to 4 units can be connected.

Battery connecting cables are not supplied with the product. Prepare connecting cables by yourself for series or parallel connection. OT terminals are recommended for cables to ensure sufficient contact surface of terminals.

PRODUCT FEATURES

Direct drop-in replacement for lead-acid batteries; no modification to existing chargers or inverters required in most applications.

Built-in Battery Management System (BMS) providing comprehensive protection against over-charge, over-discharge, over-current, short circuit, and extreme temperatures.

IP65 protection rating - dust-tight and water-jet protected, suitable for

indoor and sheltered outdoor installations.

Cycle life of >=2000 cycles at 80% depth of discharge, significantly

reducing total cost of ownership compared to lead-acid batteries.

High energy density and lightweight design - approximately 1/3 the weight of an equivalent lead-acid battery.

Wide operating temperature range with stable discharge performance.

Low self-discharge rate and maintenance-free operation.
