MSF-2KW 24V200AH Solar Power And Storage Small And Compact System
MSF-2KW 24V200AH MSF series integrates PV MPPT, inverter, controller, and battery into one set. It is an independent small solar BESS station, specifically designed to bring comfort and great convenience as well as high efficiency to households.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
System Features
1.Pure Sine Wave Output, Adaptable to Different Loads
2.UPS Function, Transfer Time ＜20ms
3.PWM / MPPT Solar Controller are Optional
4.Inverter and Battery Capacity Can be Customized
5.Configurable Proportion of Photovoltaic,Mains, and Battery Input
6.Multiple Working Modes:Photovoltaic/Battery/ AC priority
7.Equipped with Pulleys and Handles for EasyMovement and Installation
| Model | MSF- 1KW12V100AHP |
MSF- 1KW12V280AHP |
MSF- 2KW24V100AHM |
MSF- 2KW24V200AHM |
MSF- 3KW51.2V100AHM |
MSF- 3KW24V280AHM |
| Solar Input Data | ||||||
| Efficiency | >85% | >97% | ||||
| Charging Method | PWM | MPPT | ||||
| Max.PV Voltage | 50V | 145V | ||||
| Rated PV Charging Voltage |
13.7V | 27.4V | ||||
| Rated AC Charging Current |
5~10A | 60A | 120A | |||
| Max.Power | 800W | 1600W | 3200W | |||
| Overcharge Protection Voltage |
14.2VDC | 28.4VDC | 56.5VDC | 28.4VDC | ||
| Float Charging Voltage |
13.7V | 27.4V | 54V | 27.4V | ||
| AC Input Data | ||||||
| Rated Voltage | 220VAC(Standard)/110VAC(Customized) | |||||
| Charging Curent | 12A(10-20A Adjustable) | 20A (15-30A Adjustable) |
30A (15-30A Adjustable) |
|||
| Inverter | ||||||
| Rated Power | 1000W 2000W 2400W | |||||
| Output Voltage | 220VAC(Standard)/110VAC(Customized) | |||||
| Output Frequency | 50Hz/60Hz | |||||
| Output Waveform | Pure Sine Wave | |||||
| DC Output Data | ||||||
| High Voltage Protection Voltage |
16VDC | 32VDC | 59VDC | 32VDC | ||
| High Voltage Recovery Voltage |
15.2VDC | 30.4VDC | 56VDC | 30.4VDC | ||
| Low Voltage Recovery Voltage |
13VDC | 26VDC | 47VDC | 26VDC | ||
| Low Voltage Protection Voltage |
11VDC | 22VDC | 42VDC | 22VDC | ||
| 5VDC USB Output Port |
2 Units(MAX 2A) | 1 Units (MAX 2A) | ||||
| 12VDC Output Port | 2 DC Ports(MAX 5A) | 1 DC Ports (MAX 5A) | ||||
| Battery | ||||||
| Battery Type | Gel/Lead-acid/LiFePO4 | LiFePO4 | ||||
| Battery Voltage | 12V | 24V | 51.2V | 24V | ||
| Battery Specification | 100AH/12V 280AH/12V | 100AH/12V*2 | 100AH | 280h/12V*2 | ||
| General Data | ||||||
| Warranty | 1 Year (LiFePO4 Battery:2-Year) | |||||
| Operating Temperature |
0℃-40℃ | |||||
| Storage Temperature | -25℃-55℃(LiFePO4 Battery:-10℃-50℃) | |||||
| Operating Humidity | 0%-90%RH (Non-condensing) | |||||
| Dimensions (W-D'H) | 260*410*440mm 380*434*539mm 320*515*545mm(Packaged) 480+535*640mm(Packaged) |
384*444*539mm 480*550*640mm (Packsged) |
||||
| Safety Standard | EN-IEC 60335-1,EN-IEC 60335-2-29,IEC 62109-1,CE,UN38.3,MSDS | |||||
