H Type Branch PV Connector
ONESUN H Type Branch PV Connector is a part of the circuit that connects multiple solar cell modules into a system. It can also be said to be a more formal terminal block, or a quick connector, which can be plugged and connected at any time.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Description
The connector is a part of the circuit that connects multiple solar cell modules into a system. It can also be said to be a more formal terminal block, or a quick connector, which can be plugged and connected at any time.
Features
Material：PPO plastic body + copper tinned car hardware
Specification：The adapter is a set of male and female joint, which is mostly used for system parallel PV plate
Certificate：CE/ROHS
Product Dimensions
ONESUN MCH201
ONESUN MCH301
ONESUN MCH401
ONESUN MCH501
Parameters
|
Product Name |
ONESUN MCH201 |
ONESUN MCH301 |
ONESUN MCH401 |
ONESUN MCH501 |
ONESUN MCH601 |
|
Rated voltage |
1000V |
||||
|
Insulation material |
PPO |
||||
|
Conductor material |
Copper tin-plated |
||||
|
Ambient temperature |
-40℃~+95℃ |
||||
|
Product temperature |
-40℃~+135℃ |
||||
|
Security class |
DCII |
||||
|
Waterproof grade |
IP68 |
||||
|
Contact resistance |
≤0.35mΩ |
||||
|
Connection system |
Multi-point connection |
||||
|
Self-locking system |
Embedded |
||||
|
Insertion force |
≤50N |
||||
|
Pulling out force |
≥50N |
||||
|
Rated current |
50A |
||||
|
Flame retardant rating |
UL94-VO |
||||
Application scenarios
Roof
Outdoor
Street light
FarmProduction Dispaly
Quality Assurance
H-type branch photovoltaic connector quality assurance:
1: Raw material control: The production raw materials of H-type branch photovoltaic connectors are strictly made of high-strength and high-wear-resistant raw materials to ensure product quality.
2: The essence of production: Quenching one-time forging molding Twelve years of forging production skills.
3: Quality inspection: Multiple overload limit tests for finished products to select high-quality and high-quality products for supply.
4: Complete equipment: complete in size and specification, can be used in various lifting environments.
