Standing Lithium Lron Battery
A-grade LiFePO4 Cells from Top 5 Brands
Cycle Life: ≥ 6000 Times @ 80% DoD
Support LED Screen
Compatible with Mainstream Inverters
Intelligent BMS, Automatic Restoration and Maintenance-free
Support GPS Positioning
Parallel Operation Up to Maximum 15 Units
10 Years Warranty, 15 Years Lifespan
Lifetime Technical Support
Send Inquiry
Add To Inquiry
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
| Model | S-51.2V280AH |
| Cell Type | LiFePO4 |
| Nominal Capacity | 280Ah |
| Scalability | Max.16pcs in parallel |
| Energy | 14.336KWh |
| Nominal Voltage | 51.2V |
| Operating Voltage Range | 43.2V~57.6V |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max. Charge/Discharge Current | 280A |
| Continuous Charge/Discharge Current | 140A |
| Acquisition accuracy | Voltage accuracy:±10mV |
| Current accuracy:±2% | |
| SOC accuracy:±5% | |
| SOC estimation | YES |
| Intelligent balance | YES |
| GPS positioning | YES |
| sleep and wake-up | YES |
| Protection | Over-charge, Over-discharge, Over-current, Short-circuit, Over-voltage, Under-voltage, Over-high/low temperature |
| Ingress Protection | IP 20 |
| Communication Protocol | RS485 / CAN / RS232 / BT (Optional) |
| Operating Temperature | Charging: -20℃~65℃ ; Discharging: -30℃~70℃ |
| Storage Temperature | -10℃~40℃ |
| Altitude | ≤2000m |
| Humidity | 5%~95%(non-condensing) |
| Cooling | Natural |
| Cycle Life | DOD≥80%&(≥6000 Time-PRO/≥3000 Time-SMA) |
| Warranty | 10years-PRO/5years-SMA/3years-ECO |
| Shell Material | Metal |
| Size | 500*260*870mm |
| Weight | Approx. 115.3kg |
| Certification | CE-EMC, UN38.3, MSDS |
