Home Solar Energy Storage
ONESUN low voltage battery with voltage 51.2V and capacity 100AH/200AH It adopts A grade gotion lithium cell, which has high safety and stability. Nominal capacity is 100AH, suitable for PV energy storage system, electric vehicles and other application scenarios. The cycle life (80% DOD) is 6000 times, with a long service life. Weight is about 42.4/92kg.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Description
ONESUN Stacked lithium battery is a combination of multiple batteries to achieve high-voltage output. Many of the laminated batteries are used in combination with normal dry cells, so they can be removed and replaced, but you are not recommended to remove the lithium battery because it is very dangerous.
Features
◆Famous battery cells: We only use A-grade battery cells and good quality raw materials.
◆Self-developed BMS: There are few factories that do both battery pack and BMS. ONESUN has applied BYD automotive BMS technology into energy storage field.
◆BYD Battery technology expert: The core personnel of our technical team is from BYD. He uses BYD automotive-grade smart BMS technology, so our energy storage system has the highest level of safety and quality and can withstand the test of harsh environments.
◆Experienced: 20-year industry experience, 8-year factory operation experience. Our products have been upgraded and iterated many times, which accumulates a lot of experience in dealing with problems. BMS has been upgraded and iterated to the 8th generation.
◆ODM project supported: We have BMS development capability; we can customize in electronic, electrical design, structure, communication protocol, etc. We also have experience in ODM projects.
◆Global insurance: Each battery is insured by PICC (The People's Insurance Company (Group) of China Limited). Worldwide trade safety is guaranteed. Few companies purchased insurance for their products.
◆Multiple application areas: energy storage, AGV/RGV robotics, industrial equipment, lithium electric vehicles.
Parameters
| Item | SUNIZE-B51.2V100AH | SUNIZE-B51.2V200AH |
| Cell Type | LiFePO4 | |
| Typical Capacity | 100AH | 200AH |
| Minimum Capacity | 98Ah | 196Ah |
| Nominal voltage | 51.2V | |
| End-of-charge Voltage | 58.0V+1.0V | 58.4V |
| End-of-discharge Voltage | 40.5V+2.0V | 40.0V |
| Max Charge Current | 100A | 200A |
| Max Continuous Discharge Current | 100A | 100A |
| Instantaneous Max Discharge Current | 100A±5A/s | 200A |
| Over Current Protection | 120A±15A/100ms | 120A |
| Protection Function | OCVP/UVP/OCP/SCP etc./OTP | |
| Communication Type | RS485 / CAN | |
| Operating Temperature | Charging : 0℃~45℃ | |
| Discharging: -15℃~60℃ | ||
| Cycle Life | 3000 times/4000 times/5000 tines/6000 times | |
| Storage Temperature | -5℃~35℃ | |
| Storage Humidity | ≤75% RH | |
| Standard Environmental Condition | Temperature: 25±2℃ | |
| Humidity: 45-75%RH | ||
| Atmospheric Pressure: 86-106 KPA | ||
| Discharge Connector | quick connector | M8 Terminal |
| Charge Connector | quick connector | M8 Terminal |
| Shell Material | Metal | |
| Shell Color | White | |
| Size | 585mm*360mm*165mm | 585mm*460mm*360mm |
| Weight | Approx：42.4 kg | Approx：92 kg |
Product display
