500KW Project Solution Commercial And Industrial Energy Storage System
ATS Requirement: The existing setup already includes a combination of grid power and a diesel generator, with an ATS currently installed on site. As such, we may not require an additional ATS unless your system is custom-built and must be integrated into the existing configuration....
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
ATS Requirement: The existing setup already includes a combination of grid power and a diesel generator, with an ATS currently installed on site. As such, we may not require an additional ATS unless your system is custom-built and must be integrated into the existing configuration.
Containerization: Our preference is for the entire system to be containerized.
|
Configuration |
Panels |
PV Capacity |
Battery Capacity |
Inverter Capacity |
|
Option 1 |
2, 167 nos × 600 W |
1.30 MWp |
3.4 MWh |
500 kW |
|
Option 2 |
1, 084 nos × 600 W |
650kWp |
1 MWh |
500 kW |
System iopology Diagram
System Effect Drawing
System Internal Layout
20 foot standard container BESS
System Parameter Table
|
Battery |
|
|
Total Capacity (KW) |
3344 |
|
DC Norminal Voltage (v) |
1331 |
|
Voltage Range (v) |
1102.4-1497.6 |
|
Cycle Life |
≥8000 Times & DOD≥80% |
|
Battery Cell |
|
|
Cell Type |
LiFePO4 |
|
Nominal Voltage |
3.2V |
|
Nominal Capacity |
314AH |
|
Working Temperature |
Charge:0~60℃ |
|
Discharge:-20~60℃ |
|
|
Energy Density |
174wh/kg/≈394wh/L |
|
Energy Efficiency |
≥94%(@25℃ ,0.5P) |
|
Cycle Life |
≥8000 cycles |
|
Internal Resistance |
≤0.3mΩ |
|
Charg/Discharge Rate |
0.5C/0.5C |
|
Voltage Range |
2.5~3.65V(T>0℃) |
|
2.0~3.65V(T≤0℃) |
|
PCS DATA |
|
|
DC Voltage Range |
630-1550V |
|
Max. DC Power |
636KW |
|
Max. DC Current |
908A |
|
Rated AC Power |
520KW |
|
Max. AC Power |
624KW |
|
Rated AC Voltage |
400V/50/60Hz |
|
Rated AC Current |
748A |
|
THDi |
<2.5% |
|
Working Temperature/Humidity Range |
-25~60℃/0-95%RH |
|
Max. Effeciency |
0.99 |
|
Noise |
65dB |
|
Cooling Method |
Forced air cooling |
|
STS |
500KW |
