Hybrid Inverter 48V
SHH series is single-phase low-voltage grid-connected inverter with parallel connection function, which is cost-effective and suitable for users who need to generate and sell electricity.2 years warranty, currently mainly sold to the Middle East, Southeast Asia, Europe, regions.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
ONESUN Smart hybrid solar inverter
- PF=1
- Pure sine wave output
- efficiency >98%
- Supports dual output
- Support battery-free operation
- Hybrid working modes: photovoltaic/utility/battery priority
- Three anti paint: waterproof, moisture-proof, and corrosion-resistant
Key Features
Hybrid solar Inverter(on/off grid inverter).
Output power factor PF-1.0.
On-grid with energy storage .
Configurable AC/Solar Charger priorty via LCD setting.
Smart battery charger design for optimized battery performance.
Overload, Over tem perature, Short circult protection. Fault record, History record.
External WIFI devices.
Parallel operation wlth up to 6 units.
Product Parameter
| Model | SHH-5KW | SHH-8KW | SHH-11KW |
| Input Data | |||
| Input Format | L+N+PE | ||
| Rated Charge Voltage | 220/230/240VAC | ||
| Voltage Range | 90-280VAC±3V（Normal Mode) ; 170-280VAC±3V（UPS Mode） | ||
| Frequency Range | 50Hz / 60Hz (Self-adapting) | ||
| Output Data | |||
| Rated Power | 5000W | 8000W | 11000W |
| Rated Output Voltage | 220/230/240VAC±5% | ||
| Rated Output Frequency | 50/60Hz±0.1% | ||
| Output Waveform | Pure Sine Wave | ||
| Switching Time(Settable) | 10ms (For Personal Computers) ; 20ms (For Home Appliances) | ||
| Peak Power | 10000VA | 16000VA | 22000W |
| Overload Capacity (Battery Mode) | 21s@105%~150% Load; 11s@150%~200% Load; 400ms@>200% Load | ||
| On-grid Data | |||
| Output voltage | 220/230/240VAC | ||
| Voltage Range Fed into Grid | 195-253VA | ||
| Frequency Range Fed into Grid | 49-51±1Hz/59-61±1Hz | ||
| Nominal Output Current | 21.7A | 34.7A | 47.8A |
| Power Factor | >0.99 | ||
| Max. Efficiency | 98% | ||
| Battery Data | |||
| Rated Voltage | 48Vdc | 48Vdc | 48Vdc |
| Constant Charge Voltage | 56.4Vdc | 56.4Vdc | 56.4Vdc |
| Floating Charge Voltage | 54Vdc | 54Vdc | 54Vdc |
| Charger | |||
| PV Charging Mode | MPPT | MPPT * 2 | MPPT * 2 |
| PV Max. Input Power | 5500W | 2×4000W | 2×5500W |
| MPPT Input Voltage Range | 120~500Vdc | 90~500Vdc | 90~500Vdc |
| Optimal Vmp Operating Range | 300~400Vdc | 300~400Vdc | 300~400Vdc |
| Max. PV Input Voltage | 500Vdc | 500Vdc | 500Vdc |
| Max. PV Input Current | 20A | 18A/18A | 18A/18A |
| Max. PV Charging Current | 100A | 120A | 150A |
| Max. Grid Charging Current | 60A | 60A | 60A |
| Max. Charging Current | 100A | 120A | 150A |
| Display & Interface | |||
| LCD | LCD display operating mode, load, input, output, etc | ||
| RS232 | Baud Rate 2400 | ||
| Extendable Communication Interface | Lithium Battery BMS Communication, WIFI, Dry Contact, etc | ||
| Parallel Interface | Yes | ||
| General Data | |||
| Operating Temperature | 0~40℃ | ||
| Storage Temperature | -15℃~60℃ | ||
| Operating Humidity | 20%~95% (Non-condensing) | ||
| Altitude | ≤1000m (Derate occures when ＞1000m, MAX 4000m, Refer to IEC62040) |
||
| Noise | ≤50dB | ||
| Dimensions (D*W*H) | GA:495x312x125 GL:495x312x146 | 570.8x500x148.2mm | |
| Net Weight | Approx. 8.5kg | Approx. 9.0kg | |
| Safety Standard | EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1 | ||
Products Display
ONESUN Production line
